UNIT SPECIFICATIONS
Condenser set:
Height - 235 mm Above floor
Width - 460 mm
Depth - 440 mm
Weight - 30 kg
Air Handler:
Height - 220 mm
Width - 385 mm
Depth - 230 mm
Weight - 4 kg
Minimum cupboard dimensions:
300 high x 500 wide x 305 deep
Cooling output: 2.2 KW
Heating output: 1.5 KW
Maximum current (cooling): 4.0 amps
Maximum current (heating): 6.5 amps
Maximum locked rotor current: 19 amps
Refrigerant: R22
Charge: 650 grms.
Air volume (max) Air Handler: 110 l/s
Compressor: Sanyo KR6102
Resistance run wdg.: 2.8Ω
Resistance start wdg.: 4.3Ω
Capacitor: 20 mfd. 440 vac
Fan (Air handler):
Resistance run wdg.: 165Ω
Resistance aux wdg.: 265Ω
Capacitor: 1.5 mfd. 440 vac
Fan (Condenser set):
Resistance run wdg.: 168Ω
Resistance aux wdg.: 150Ω
Capacitor: 2.5 mfd. 440 vac
