II. Technical specications
Generator model number 8896431
Generated voltage (nominal)
1)
230 V~50 Hz
400 V~50 Hz
Operating (nominal) el. power output COP
2)
230 V: 11 kW (kVA)
400 V: 11 kW (13.75 kVA)
Max. el. power output
3)
230 V: 12 kW (kVA)
400 V: 12 kW (15 kVA)
Drawn operating (nominal) input power from the power socket
16 Apower socket: ≤3.5 kW
32 Apower socket: ≤7.3 kW
400 V power socket: ≤11 kW
Total operating (nominal) current I
COP
(for el. power output of 11 kW)
I
COP
230 V: 47.8 A
I
F(COP)
400 V: 19.9 A(phase current)
Nominal/shut-o current of circuit breakers (I
n/
I
TRIPS
)
16 Acircuit breaker: 16 A/18.4 A
32 Acircuit breaker: 32 A/36.8 A
48 Acircuit breaker: 48 A/55.2 A
3-phase circuit breaker: 20 A/23 A
Power factor cos ϕ 1(230 V)/0.8 (400 V)
IP number IP23M
Power characteristic class
4)
(ISO 8528-1) G2
Quality class
5)
(ISO 8528-8) A
Ambient temperature for operation of the generator -15°C to +40°C
Fuel tank capacity 30 l
Fuel consumption at 100 % nominal power approx. 6l/11 kWh
Operating time per single fuel tank at 100 % and 50 %nominal power
approx. 5hours/100 % load;
10 hours 50 % load
Max. dimensions of the generator with wheels (H × W × D) 810 × 995 × 640 mm
Max. dimensions of the generator without wheels (H × W × D) 740 × 995 × 640 mm
Weight of generator with wheels without operating uids 190 kg
Standard spare parts available for purchase if required
Air lter (g.11D) –part number 8896431B (layered paper)
Replacement starter set –part number 8896431A
Petrol lter (g. 2, position 1) –part number 8896431F
Oil lter (g. 4, position 6) –part number 8896431G
Battery parameters for electrical start
Gel lead-acid; 12 V, 36 Ah, 10 Hr;
battery dimensions so it ts
(particularly width and depth)
H × W × D: 20 × 19 × 12.3 cm
Voltage regulation
6)
AVR
Sound pressure level, uncertainty K 86.5dB(A); K= ±2.5 dB(A)
Sound power level, uncertainty K 96.5dB(A); K= ±2.5 dB(A)
Guaranteed emission level of acoustic power (2000/14 ES) 99 dB(A)
Table 1
