Hertz HDP 5 - Battery;Remote Connection and Fuse Replacement; Auto Turn-On with Hi-Level Inputs

7
BATTERY / REMOTE CONNECTION AND HOW TO REPLACE THE FUSE
AUTO TURN-ON WITH HI-LEVEL INPUTS
HDP 5
REMOTE
VOLUME
CONTROL
HI-IN
AUTO
TURN-ON
L
R
L
R
A PRE - IN B PRE - IN
- +
A BON OFF
SUB
HI - IN
B
INPUT
A+B SUB
SUB
INPUT
A HI - IN B HI - IN
HDP5
SUB PRE - IN
+BATTERY
GND
2 x 40 A
BLADE FUSES
REMOTE OUT
Advanced Web Manual
ORIGINAL SOURCE
ORIGINAL
SOURCE
Apply a Fuse
close to positive
pole to protect
+BATTERY wire
Set the
“HI AUTO TURN-ON”
switch to the
“ON” position
Set the “HI AUTO TURN-ON”
switch to the “ON” position
