13
1.18 Parts Inspire 40
Pos. No. Name Qty.
1 5013-0008 Handle 1
2 5013-0009 Set of glass clips 1
3 0021-0053 Glass 1
4 4005-0042 Door, with glass tape 1
5 0008-9086 Hinge Pin 2
6 0023-3013 Glass seal 3x8 mm 1.3 m
7 0023-3008 Door seal ø12 1.5 m
8 1020-0001 Handle for ash pan 1
9 1018-0216 Ash pan 1
10 0030-0020 Cast bottom 1
Pos. No. Name Qty.
11 0030-0201 Shaking grate, Ø195 mm 1
12 0015-2013 Shaking grate handle 1
13 1019-0028 Log retainer 1
14 0023-0197 Baffle plate 1
15 0023-0153 Left stone 1
16 0023-0152 Right stone 1
17 0023-0194 Left back stone 1
18 0023-0195 Right back stone 1
19 0023-0196 Bottom stone 2
- 1
- 2 x4
3 -
4 -
- 5 x2
- 6
7 -
- 8
- 9
- 10
- 11
- 12
13 -
14 -
15 -
- 16
- 17
18 -
- 19 -
