ABOUT YOUR RECEIVER
DESCRIPTION AND FEATURES
GENERAL DESCRIPTION
The RX 14-HL is an expandable receiver baseboard
that has been designed to work in conjunction with a
variety of transmitters. See your transmitter
documentation for detailed transmitter information.
Optional expansion boards may be installed within
the receiver housing.
For more information regarding expansion boards
contact Hetronic or your dealer.
Figure 1: Receiver Housing, Baseboard and Optional Expansion Boards
Receiver
Housing
RX 14-HL Baseboard
Optional Expansion Boards
RS-232
Port
Status
Lights
