You will need to reboot your board after making those changes.
To enable streaming the ADSB data to the GCS you’ll want to check your StreamRate param. In some cases it
is already set but it’s good to check. These rates are adjustable per telemetry like in the case of having both
a high-bandwidth and a low-bandwitdh link attached. The param to adjust the rate would depend on which
one your GCS is connected to. In most cases, it is TELEM1 .
SR1_ADSB = 5 (meaning 5 Hz)
Once operational aircraft within about 50km should appear on the Mission Planner map.
OSD (On-Screen Display)
Optional OSD Module
An optional OSD (On Screen Display) module receives real-time data from vehicle and overlay those
information on the camera. The video is then streaming through video transmitter and can be viewed in the
GCS. To enable video display, Connect the 6 pin DF13 cable from the module to TELEM2 on The Cube.
Last Update: 11th June 2019
