HH ACTIVE PA SETUP DIAGRAM
HH ACTIVE PA SETUP DIAGRAM
Line level signals can be connected to the input using a balanced or unbalanced XLR or a 6.3mm jack.
The input signal can be supplied to another active device through a Male XLR in the Link Output socket.
*all cables balanced
Main Outputs L/R
HH Active PA
HH Active PA
Mixer
Input
Link
Input
Link
