Hi-Link HLK-7628D User Manual

Shenzhen Hi-Link Electronic Co., Ltd. Manual
page 1 / 15
HLK-7628D
1. Product description
HLK-7628D module from Hi-Link is a low-cost, low-power IoT module based on MediaTek's MT7628DN.
This module introduces all interfaces of MT7628DN, supports Linux and OpenWrt operating system and custom
development, has rich interface and powerful processor, can be widely used in smart devices or cloud service
applications as well as freely second-developed.
1.1. Basic parameters

Super data processing capability, MCU frequency up to 580MHz

150M wireless rate

Support 802.11b/g/nmode

20/40 channel bandwidth

Support 802.11v

Support AP, STA and AP, STA mixed mode

5 10/100M adaptive network ports

1 USB2.0 host interface

Multiple interfaces SPI/SD-XC/eMMC

Rich peripheral interface, SPI, I2C, I2S, PCM, UART, JTAG, GPIO

Widely used in the Internet of Things

Built-in powerful PMU

Support 16 Multiple BSSIDs

Support multiple encryption methods WEP64/128, TKIP, AES, WPA, WPA2, WAPI

Support QoS, WMM, WMM-PS

Support multiple systems, Linux 2.6.36 SDK, OpenWrt 3.10
