Hi-Link HLK-7688A User Manual

７
I/O I/O voltage 3 3.3 3.6
3.2. RF PERFORMANCE
3.2.1. 802.11b 11M
802.11b Transmit (Conductive)
Item Condition Min. Typ. Max. Unit
Frequency Range Channel 1 Channel 11
Tx Power Level DQPSK 14 20 16 dBm
Frequency Tolerance -15 0 15 ppm
Spectral Mask
11MHz→22MHz 40 dBr
＞22MHz 53 dBr
Modulation Accuracy All Data Rate 15 %
802.11b Receiver (Conductive)
Item Condition Min. Typ. Max. Unit
Frequency Range Channel 1 Channel 11
Min. Input 11Mbps PER<8% -91.5 -89.5 -87.5 dBm
3.2.2. 802.11g 54M
802.11g Transmit (Conductive)
Item Condition Min. Typ. Max. Unit
Frequency Range Channel 1 Channel 11
Tx Power Level OFDM 9 17 11 dBm
Frequency Tolerance -15 0 15 ppm
Modulation Accuracy All Data Rate -31 -28 %
802.11g Receiver (Conductive)
Item Condition Min. Typ. Max. Unit
Frequency Range Channel 1 Channel 11
