Hi-Link HLK-7688A - HLK-7688 A Module Pin Definitions; HLK-7688 A Default Pinout Diagram

９
Frequency Range Channel 1 Channel 11
Min. Input MCS7 PER<10% -76.5 -74.5 -72.5 dBm
4. MODULE PINS DEFINITION
4.1. DEFAULT PINS DEFINITION
HLK-7688A default definition
4.2. DEGAULT PINS DEFINITION
