Hi-Link HLK-7688A User Manual

８
Min. Input 54Mbps PER<10% -78.0 -76.0 -74.0 dBm
3.2.3. 802.11n MCS7(HT20)
802.11n_HT20 Transmit (Conductive)
Item Condition Min. Typ. Max. Unit
Frequency Range Channel 1 Channel 11
Tx Power Level OFDM 9 17 11 dBm
Frequency Tolerance -15 0 15 ppm
Modulation Accuracy All Data Rate -31 -28 dB
802.11n_HT20 Receiver (Conductive)
Item Condition Min. Typ. Max. Unit
Frequency Range Channel 1 Channel 11
Min. Input MCS7 PER<10% -76.5 -74.5 -72.5 dBm
3.2.4. 802.11n_MCS7(HT40)
802.11n_HT40 Transmit (Conductive)
Frequency Range Channel 1 Channel 11
Tx Power Level OFDM 5.0 17.0 8.0 dBm
Frequency Tolerance -15 0 15 ppm
Modulation Accuracy All Data Rate -31 -28 dB
802.11n_HT40 Receiver (Conductive)
Item Condition Min. Typ. Max. Unit
Item
Condition
Min.
Typ. Max.
Unit
