Hi-Link HLK-RM60 User Manual

User Manual
- 9 -
I2C Interface：
75 75:I2C_SCLK
I/O
I2C_SCLK/GPIO#3 GPIO#3
77 77:I2C_SDA I2C_SDA/GPIO#4 GPIO#4
Network port P0 System reset：
8 ESW_TXVP_A_P0
PORT0 Interface
Network port 0 ， Please leave it in the air if you don;t
need it
10 ESW_TXVN_A_P0
12 ESW_TXVP_B_P0
14 ESW_TXVN_B_P0
16 ESW_TXVP_C_P0
18 ESW_TXVN_C_P0
20 ESW_TXVP_D_P0
22 ESW_TXVN_D_P0
Network port P1 Interface：
26 ESW_TXVP_A_P1
PORT1 Interface
Network port 1，Please leave it in the air if you don;t
need it
28 ESW_TXVN_A_P1
30 ESW_TXVP_B_P1
32 ESW_TXVN_B_P1
34 ESW_TXVP_C_P1
36 ESW_TXVN_C_P1
38 ESW_TXVP_D_P1
40 ESW_TXVN_D_P1
Network port P2 Interface：
44 ESW_TXVP_A_P2
PORT2 Interface
Network port 2，Please leave it in the air if you don;t
need it
46 ESW_TXVN_A_P2
48 ESW_TXVP_B_P2
50 ESW_TXVN_B_P2
52 ESW_TXVP_C_P2
54 ESW_TXVN_C_P2
56 ESW_TXVP_D_P2
58 ESW_TXVN_D_P2
