2. Product Overview 3. Assembly
32
4. Accelerator/Throttle
1. LED dispaly
2. Handle
3. Brake
11. Anti-slip Pedal
10. Battery Compartment
12. Kickstand
7. Rear Fender
9. Disc Brake
8. Tail Light
13. Front Fender
6. Folding Spanner
15. Shock Absorber
14. Motor
5. Headlight
1. Press down on the folding spanner with your feet. 2. Unfold the stem and push it until you hear a click.
Then unfold the kickstand to support the scooter.
3. . Install the brake, then use the allen wrench
(the biggest one)to tighten it.
4. Rotate in counterclockwise direction to install the
two handles. Then verify that your scooter powers
on and off.
To Next Page
