11. Specifications
Operating Temperature
(1) The height of the body: distance from the ground to the highest end of the body.
(2) Description of the battery life: it is measured under the condition of full charge, a load of 150 lb, at 77°F , on a flat road without wind, and at
a speed of 9.3mph. The real battery life will differ with different factors of the load, humidity, wind speed and operation habits.
(3) The maximum allowable weight shall be kept within 220lb (driver and objects included)in any case. Consider an extra weight of the clothes
or other accessories with us during the trip and the gravity generated by speed, the scooter will not support it if this load limit is exceeded.
1. Seat components a, b, c 2. Insert b into a
3.
Make b perpendicular to a, and
tighten it with wrench
4.
Insert the seat into c, and tighten
the screw rod and press down the
seat clamp as shown in the figure.
5.
The seat assembly is completed 6. Insert the assembled seat into the
hole on the scooter.
7. Open the safety ring. 8. Pull the fixed handle and put the
seat down
9.
Tighten screw with a hexagonal
wrench.
10. Fasten the fixed handle. 11. Lock the safety ring. 12. Seat assembly completed.
* The seat is not included, please purchase separately from hiboy store*
12. Instructions of Seat Assembly(Option)
45.7*17.0*47.2inch
45.7*17.0*19.3inch
28.7lb
265lb
15.5mph
17mile
14-104 °F
15
14
Max. Range
Max. Load
3h-5h
350W
2A
