LED Description
IN7 Input IN7 status: OFF = Inactive, ON = Active, Flash = Fault.
1
IN8 Input IN8 status: OFF = Inactive, ON = Active, Flash = Fault.
1
K1 Relay K1: ON = Energized
K2 Relay K2: ON = Energized
K3 Relay K3: ON = Energized
K4 Relay K4: ON = Energized
1. If this input is defined, every three seconds the LED is pulsed to its opposite state for 0.1 seconds, otherwise, the LED is off.
2.12 IT security
Ensure that the LP1502 is installed securely. Create user accounts to the web configuration page using secure
passwords.
Ensure all DIP switches are to be in the OFF position for the normal operating mode.
The LP1502 is shipped from the factory with a default login account, which is enabled when DIP 1 is moved
from OFF to ON (See DIP switches). The default login user name (admin) and password (password) will be
available for five minutes once the DIP switch is toggled. It is therefore important that at least one user
account is defined, and the DIP switches are set to OFF before the LP1502 is commissioned.
Configuring the LP1502 with an IP address that is accessible from the public is not recommended.
The following options are available for enhanced network security:
n Disable SNMP.
n Zeroconf discovery.
n The web configuration module.
n Enable data encryption over the host communication port.
PLT-05244, A.3 17 June 2021
