HID Mercury LP4502 User Manual

2.1 LP4502 connections
TB1-1 GND Power fault input
TB1-2 FLT
TB1-3 GND Cabinet Tamper input
TB1-4 TMP
TB1-5 GND Power input
TB1-6 VIN: 12 to 24 V
DC

TB2-1 GND SIO port 1 (2-wire RS-485)
TB2-2 TR- (A)
1
TB2-3 TR+ (B)
1
TB3-1 GND SIO port 2 (2-wire RS-485)
TB3-2 TR- (A)
1
TB3-3 TR+ (B)
1

TB4-1 IN2 Input 2
TB4-2 IN2
TB4-3 IN1 Input 1
TB4-4 IN1

TB5-1 IN4 Input 4
TB5-2 IN4
TB5-3 IN3 Input 3
TB5-4 IN3

TB6-1 IN6 Input 6
TB6-2 IN6
TB6-3 IN5 Input 5
TB6-4 IN5

TB7-1 IN8 Input 8
TB7-2 IN8
TB7-3 IN7 Input 7
TB7-4 IN7

PLT-05246, A.4 7 June 2021
Powering
Trusted Identities
HIDMercury™ LP4502 Controller
Installation and Specifications

HID Mercury LP4502 Specifications

General

Brand	HID
Model	Mercury LP4502
Category	Controller
Language	English
