Hikmicro Falcon Series User Manual

Thermal Monocular User Manual
15
Red Hot
The hot part is red-colored in view. The higher the temperature is, the
redder the color is.
Fusion
From high temperature to low temperature, the image is colored in from
white, yellow, red, pink to purple.

Hikmicro Falcon Series Specifications

General

Pixel Pitch	12 μm
Lens Options	19 mm / 25 mm / 35 mm / 50 mm
Aperture	F1.0
Refresh Rate	50 Hz
Digital Zoom	1x, 2x, 4x, 8x
Video Recording	Yes
Photo Capture	Yes
Wi-Fi	Yes
Standby Mode	Yes
Protection Level	IP67
Detector Type	Uncooled Focal Plane Arrays
Resolution	640 x 512
Detection Range	1800 m
Display	0.39-inch OLED, 1024 × 768
Image Modes	Black hot, white hot, red hot, fusion
Battery Type	Rechargeable Li-ion
Operating Temperature	-30 °C to 55 °C
