Hikmicro Falcon Series User Manual

Thermal Monocular User Manual
19
Figure 3-6 Correct Defective Pixel
Note

The selected defective pixel can be magnified and displayed on the
bottom right of the interface.

If the screen OSD blocks the defective pixel, move the cursor to reach
the defective pixel, then the device performs mirror display
automatically.

Hikmicro Falcon Series Specifications

General

Pixel Pitch	12 μm
Lens Options	19 mm / 25 mm / 35 mm / 50 mm
Aperture	F1.0
Refresh Rate	50 Hz
Digital Zoom	1x, 2x, 4x, 8x
Video Recording	Yes
Photo Capture	Yes
Wi-Fi	Yes
Standby Mode	Yes
Protection Level	IP67
Detector Type	Uncooled Focal Plane Arrays
Resolution	640 x 512
Detection Range	1800 m
Display	0.39-inch OLED, 1024 × 768
Image Modes	Black hot, white hot, red hot, fusion
Battery Type	Rechargeable Li-ion
Operating Temperature	-30 °C to 55 °C
