Hikmicro Falcon Series User Manual

Thermal Monocular User Manual
27
example, if you capture a picture or record a video on November 2023,
go to DCIM -> 202311 to find the picture or video.
7. Select and copy the files to PC.
8. Disconnect the device from your PC.
Note

The device displays images when you connect it to PC. But functions
such as recording, capturing and hotspot are disabled.

When you connect the device to PC for the first time, it installs the drive
program automatically.

Hikmicro Falcon Series Specifications

General

Pixel Pitch	12 μm
Lens Options	19 mm / 25 mm / 35 mm / 50 mm
Aperture	F1.0
Refresh Rate	50 Hz
Digital Zoom	1x, 2x, 4x, 8x
Video Recording	Yes
Photo Capture	Yes
Wi-Fi	Yes
Standby Mode	Yes
Protection Level	IP67
Detector Type	Uncooled Focal Plane Arrays
Resolution	640 x 512
Detection Range	1800 m
Display	0.39-inch OLED, 1024 × 768
Image Modes	Black hot, white hot, red hot, fusion
Battery Type	Rechargeable Li-ion
Operating Temperature	-30 °C to 55 °C
