4
English
MOUNTING AND OPERATION
Action Figure Page
Mounting stopper assembly 1 51
Mounting and dismounting the bit*
1
251
Switch operation 3 51
Locking-on the On / Off switch 4 51
Releasing the On / Off switch 5 51
Selecting accessories ― 53
*1 Selecting the appropriate drill bit
(1) When drilling holes in metals or plastics:
Use ordinary metalworking drill bits;
Applicable drill sizes range from 0.5 mm min. to 6.5 mm
max.
(2) When drilling holes in lumber:
Use woodworking drill bits.
For small holes of 6.5 mm dia, or less, use metalworking
drill bits.
MAINTENANCE AND INSPECTION
CAUTION
Be sure to switch power OFF and disconnect the plug
from the receptacle during maintenance and inspection.
1. Inspecting the drill bits
Since use of an abraded drill bits will cause motor
malfunctioning and degraded effi ciency, replace the drill
bits with a new one or resharpening without delay when
abrasion is noted.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws be
loose, retighten them immediately. Failure to do so could
result in serious hazard.
3. Servicing
Consult an authorized Service Center in the event of
power tool failure.
CAUTION
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
GUARANTEE
We guarantee HiKOKI power tools in accordance with
statutory/country specifi c regulation. This guarantee does
not cover defects or damage due to misuse, abuse, or
normal wear and tear. In case of complaint, please send
the power tool, undismantled, with the GUARANTEE
CERTIFICATE found at the end of this Handling instruction,
to a HiKOKI Authorized Service Center.
SPECIFICATIONS
Model D6SH
Voltage*
1
(110 V, 220 V, 230 V, 240 V)
Power input*
1
240 W
No load speed 4500 min
-1
Capacity
Steel 6.5 mm
Wood 9 mm
Weight (without cord)*
2
Spec. for keyed chuck 0.9 kg
Spec. for keyless chuck 1.0 kg
*1 Be sure to check the nameplate on product as it is subject to change by areas.
*2 According to EPTA-Procedure 01/2014.
NOTE
Due to HiKOKI’s continuing program of research and development, the specifi cations herein are subject to change
without prior notice.
Switching OFF
Lock
Switch locks to the “ON” position.
Disconnect mains plug from electrical outlet
Class II tool
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package contains the
accessories listed in the below.
(1) Chuck Wrench (Spec. only for keyed chuck) ............. 1
(2) Stopper Ass’y (Spec. only for keyed chuck) ............... 1
(3) Hook .......................................................................... 1
Standard accessories are subject to change without notice.
APPLICATIONS
Drilling in metal, lumber and plastics.
