HIKVISION 2 MP Series User Manual

Mark Description
Table 0-1 Mark Description
Mark
Description
DC Voltage
1 Introduction
1.1 Main Features
 High performance CMOS sensor
 Low illumination, 0.01 Lux @ (F1.2, AGC ON), 0 Lux
with IR
 IR cut filter
 OSD menu with configurable parameters
 Auto white balance
 Switchable TVI/AHD/CVI/CVBS video output
 SMART IR
 3-axis adjustment
1.2 Overview
1.2.1 Overview of the Camera
DC12VIN
Mounting Base
Main Body
Enclosure
Stopper Screw
Switch Button
Power Cord
12 VDC
Video Cable
Figure 1-1 Overview of the Camera
Note:
Press and hold the switch button for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS.

HIKVISION 2 MP Series Specifications

General

IR Range	Up to 30 m
Protection Level	IP67
Video Compression	H.265+/H.265/H.264+/H.264
Resolution	2 MP (1920 × 1080)
Lens	2.8 mm, 3.6 mm, 6 mm
Power Supply	12 VDC ± 25%/PoE (802.3af)
