1 Introduction
1.1 Product Features
This series of camera adopts new generation sensor with
high sensitivity and advanced circuit design technology. It
features high resolution, low image distortion and low
noise, etc., which makes it suitable for monitoring system
and image processing system.
The main features are as follows:
� High performance CMOS sensor
� High resolution image
� Low illumination, 0.1 lux @ (F1.2, AGC ON)
� Supports auto electronic day & night switch
� Supports auto gain control
1.2 Overview
1.2.1 Overview of DBA Vehicle-Mounted Camera
The overview of the camera is shown below.
Overview
1.2.2 Cable Description
The device supports two types of cable. Connect the
device with matched cable. The cable descriptions as
below:
Aviation Plug Interface
Interfaces of Aviation Plug
