User Manual of DS-1005KI Keyboard
19
Before sending the command, make sure your PC has installed the serial port tool with Send
Ymode functions, e.g., SecureCRT 6.5.
Prompt Figure 5-2
Send upgrade file to upgrade the device. Step 5
The following steps introduce the serial port tool SecureCRT as the example to upgrade the device.
1) Open serial port tool SecureCRT 6.5.
2) Select the corresponding serial port of the device (as shown in step2) and configure the
port parameters (baud rate: 115200, data bit: 8, parity: none).
3) It will print C continuously and the upgrade file is sent directly.
SecureCRT Figure 5-3
4) Click Send Ymodem under the menu Transfer to enter the path choosing page of upgrade
patch.

HIKVISION DS-1005KI Specifications

General

Type	Joystick
Product color	Black, Silver
Placement supported	Universal
Programmable buttons	Yes
Number of joystick axis	3
Number of programmable buttons	15
Connectivity technology	Wired
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	5 V
Harmonized System (HS) code	85299020

Weight and Dimensions

Depth	177.5 mm
Width	167 mm
Height	116 mm
