HIKVISION DS-1005KI User Manual

User Manual of DS-1005KI Keyboard
21
Upgrade Completed Figure 5-6

When the upgrade is accomplished, please close the current serial port and reboot the
keyboard.

If the upgrade is failed, the digital tube of the keyboard will light always. Reboot the
keyboard, open the serial port tool and start to upgrade (step 5).
0103001070405

HIKVISION DS-1005KI Specifications

General

Type	Joystick
Product color	Black, Silver
Placement supported	Universal
Programmable buttons	Yes
Number of joystick axis	3
Number of programmable buttons	15
Connectivity technology	Wired
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	5 V
Harmonized System (HS) code	85299020

Weight and Dimensions

Depth	177.5 mm
Width	167 mm
Height	116 mm
