cleared.
4. Resume the dome activity.
You can set ALARM RESUME to ON to enable the speed dome to resume its previous activity
after the triggered actions finished.
If the speed dome is moving when a linkage action is triggered, it will stop at the current
position and resume from this position after the linkage action is finished.
The speed dome can be configured to resume the PTZ positions, focus, and iris value.
3.5.3 Configuring Auxiliary Alarm Output
Purpose:
An auxiliary alarm output is a configurable alarm output interface on the speed dome back box
which can connect and trigger another alarm device to operate.
Steps:
1. Enter the alarm output configuration submenu:
MAIN MENUS > SYS SETTINGS > AUXS
Figure 3-23 Configure the Alarm Output
2. Click IRIS+ to edit the status of the alarm outputs. You can set the auxiliary alarm output type to
OPEN (normally open) and CLOSE (normally closed).
3. Move the cursor to DWELL TIME to set the duration of the alarm output signal.
4. Link the alarm output to the configured alarm.
Steps:
(1) Enter MAIN MENUS > SYS SETTINGS > ALARMS > ALARM SETTING and choose the alarm
number that you want to link the alarm output to.
(2) Move the cursor to AUX and click IRIS+ to configure the alarm output to the alarm. You can
choose OPEN to active AUX 1.
To Next Page
