User Manual of HD-TVI Speed Dome
Move the cursor to CLEAR ZONE, click IRIS+ to clear all the settings of the current zone, and click
IRIS+ again to confirm the settings and exit.
3.5 Configuring and Handling Alarms
The alarm related function is supported by the 5-inch IR speed dome only.
3.5.1 Configuring Alarm Input and Linkage Actions
Purpose:
This section explains how to configure the speed dome to respond to alarm events with alarm
linked actions, such as calling presets, patrols, patterns, scanning, etc.
Steps:
1. Move the cursor to enter the alarm configuration submenu:
MAIN MENUS > DOME SETTINGS > ALARM INPUT
ALARM INPUT
RESUME ON
SEQUENCE 5
DELAY TIME 5
ALARM SETTING
BACK EXIT
ALARM SETTING
ALARM NO. 1
PRIORITY HIGH
LINKAGE NONE
ALARM OUTPUT NONE
ALARM INPUT OPEN
BACK EXIT
Figure 3-20 Alarm Configuration Menu
2. Choose the alarm number.
Steps:
(1) Move the cursor to ALARM NO. and click the IRIS+ to enter edit mode.
(2) Click the up and down direction buttons to select the number of the alarm which is to be
configured.
(3) Click IRIS+ again to confirm and exit edit mode of this column.
You can configure up to 2 alarm inputs.
3. Move the cursor to ALARM SETTING and click the IRIS+ to enter the setting alarm submenu.
4. Configure the alarm input.
Steps:
(1) Move the cursor to ALARM INPUT and click the IRIS+ to enter edit mode.
(2) Click the up and down direction buttons to set the input status. You can configure it as OPEN
(Normally open), CLOSE (Normally closed) or OFF (disable the alarm input).
To Next Page
