User Manual of HD-TVI Speed Dome
position and resume from this position after the linkage action finishes.
The speed dome can be configured to resume the PTZ positions, focus and iris value.
3.5.3 Configuring Alarm Output
Purpose:
An alarm output is a configurable alarm output interface on the speed dome back box which can
connect and trigger another alarm device to operate.
Steps:
1. Enter the alarm output configuration submenu:
MAIN MENUS > DOME SETTINGS > ALARM OUTPUT
ALARM OUTPUT
ALARM OUTPUT 1 CLOSE
DWELL TIME 2
ALARM OUTPUT 2 OPEN
DWELL TIME 0
BACK EXIT
Figure 3-21 Configure the Alarm Output
2. Click IRIS+ to edit the status of the alarm outputs. You can set the alarm output type as OPEN
(normally open) and CLOSE (normally closed).
There is 1 alarm output configurable; configuring the alarm output 2 will be invalid.
3. Move the cursor to DWELL TIME to set the duration of the alarm output signal. The configurable
rage is 0~60 seconds.
4. Link the alarm output to the configured alarm.
Steps:
(1) Enter MAIN MENUS > DOME SETTINGS > ALARM INPUT > ALARM SETTING and choose the
alarm number that you want to link the alarm output to.
(2) Move the cursor to ALARM OUTPUT and click IRIS+ to configure the alarm output to the
alarm. You can choose NONE to disable alarm outputs, choose 1 to active ALARM OUTPUT
1.
There is 1 alarm output configurable; configuring the alarm output 2 will be invalid.
