HIKVISION DS-2CD1043G0E-I User Manual

Network Bullet Camera·Quick Start Guide
6
● In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
● The power source should meet limited power source or PS2
requirements according to IEC 60950-1 or IEC 62368-1
standard.
● Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
● Please make sure that the plug is firmly connected to the power
socket. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
● If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then please contact
the service center.
Cautions
● CAUTION: Hot parts! Burned fingers when handling the parts.
Wait one-half hour after switching off
before handling parts. This sticker is to
indicate that the marked item can be hot
and should not be touched without
taking care. For device with this sticker, this device is intended
for installation in a restricted access location, access can only be
gained by service persons or by users who have been instructed
about the reasons for the restrictions applied to the location
and about any precautions that shall be taken.

HIKVISION DS-2CD1043G0E-I Specifications

General

Sensor type	CMOS
Progressive scan	Yes
Number of sensors	1
Optical sensor size	1/3 \
DC output current	0.35 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	4.2 W
Fixed focal length	2.8 mm
Maximum aperture number	2
Pan range	0 - 360 °
Tilt angle range	0 - 180 °
Angle of rotation	360 °
Camera shutter speed	1/3 - 1/100000 s
Minimum illumination	0.028 lx
Type	IP security camera
Certification	47 CFR 15, B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: 6, 2016; KN 32: 2015, KN 35: 2015 UL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IS 13252(1):2010+A1:2013+A2:2015, IEC/EN 60950-1
Placement supported	Outdoor
Connectivity technology	Wired
Built-in HDD	No
Total megapixels	4 MP
Maximum resolution	2560 x 1440 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology	3D noise reduction
Supported graphics resolutions	320 x 240, 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440
Number of users	32 user(s)
Networking standards	IEEE 802.1x, IEEE 802.3af
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	White
Housing material	Metal, Plastic
International Protection (IP) code	IP67

Weight and Dimensions

Depth	67.8 mm
Width	66.2 mm
Length	177.6 mm
Weight	280 g
Package depth	121 mm
Package width	216 mm
Package height	118 mm
Package weight	501 g
