HIKVISION DS-2CD2042WD-I User Manual

User Manual
Code: DS-2CD2042WD-I(4mm)
IP CAMERA DS-2CD2042WD-I(4mm) - 4.0 Mpx Hikvision
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: delta-opti@delta.poznan.pl; tel: +(48) 61 864 69 60
2021-11-10 DS-2CD2042WD-I(4mm) 3/6
Network protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP,
UPnP, SMTP, SNMP, IGMP, IEEE 802.1x, UDP, PPPoE, QoS, IPv6
WEB Server: Built-in, NVR compliance
Max. number of on-line users: 6
ONVIF: 2.6
Mobile phones support:
Port no.: 8000 or access by a cloud (P2P)
• Android: Free application iVMS-4500 or Hik-Connect
• iOS (iPhone): Free application iVMS-4500 or Hik-Connect
Default admin user / password: admin / -
Default IP address: 192.168.1.64
Web browser access ports: 80
PC client access ports: Port no.: 8000 or access by a cloud (P2P) - iVMS-4200 application
Mobile client access ports: 8000
Port ONVIF: 80
RTSP URL:
• Main stream
rtsp://192.168.1.64:554/Streaming/Channels/101/ - RTSP - without authorization
rtsp://user:password@192.168.1.64:554/Streaming/Channels/101/ - with
authorization
• Sub stream
rtsp://192.168.1.64:554/Streaming/Channels/102/ - RTSP - without authorization
rtsp://user:password@192.168.1.64:554/Streaming/Channels/102/ - with
authorization
RS-485 interface:
Main features:
• 3D-DNR - Digital Noise Reduction
• WDR - 120 dB - Wide Dynamic Range
• BLC - Back Light Compensation
• RESET button
• Possibility to change the resolution, quality and bit rate
• Intelligent Image Analysis : Motion Detection, intrusion, crossing the line (tripwire)
• ROI - improve the quality of selected parts of image
• Configurable Privacy Zones
• Mirror - Mirror image
Power supply:
• PoE (802.3af),
• 12 V DC / 410 mA
Power consumption: ≤ 5.0 W
Housing: Compact, Aluminum
"Index of Protection": IP67
Color: White
Operation temp: -30 °C ... 60 °C
Supported languages:
English, Bulgarian, Chinese, Croatian, Czech, Danish, Estonian, Finnish, French,
Greek, Spanish, Dutch, Japanese, Korean, Lithuanian, Latvian, German, Norwegian,
Polish, Portuguese, Russian, Romanian, Serbian, Slovak, Slovenian, Swedish, Turkish,
Hungarian, Vietnamese, Italian
Weight: 0.38 kg
Dimensions: 155 x 70 x 70 mm

HIKVISION DS-2CD2042WD-I Specifications

General

Wi-Fi	No
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3af
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
LED type	IR
Night vision distance	30 m
Number of cameras	1
Password protection type	-
Fixed focal length	12 mm
Maximum aperture number	2
Operating temperature (T-T)	-30 - 60 °C
Sensor type	CMOS
Optical sensor size	1/3 \
Camera shutter speed	1/3 - 1/10000 s
Minimum illumination	0 lx
DC output voltage	12
Power source type	PoE
Power consumption (max)	5 W
Total megapixels	4 MP
Maximum resolution	2688 x 1520 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, M-JPEG
Supported graphics resolutions	352 x 240, 352 x 288, 640 x 360, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Form factor	Bullet
Mounting type	Wall
Product color	White
Housing material	Metal
International Protection (IP) code	IP67
Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Interface	RJ-45

Weight and Dimensions

Depth	154.2 mm
Width	70 mm
Height	60.5 mm
Weight	500 g
