HIKVISION DS-2CD4012F-A Installation Manual

Installation Manual of Network Camera
32
Figure 3-25 Drill Template
2. Fix the ceiling mount to the ceiling with screws.
Figure 3-26 Fix the Ceiling Mount
3. Route the cables through the cable hole on the ceiling.
If required, you can rotate the side outlet on the mounting base to remove it and route the cables
through the side outlet.
Ceiling
Ceiling Mount
Lo-Call 1890 866 900
www.cctvireland.ie
shop@cctvireland.ie

HIKVISION DS-2CD4012F-A Specifications

General

Brand	HIKVISION
Model	DS-2CD4012F-A
Category	Security Camera
Language	English
