Network Dome Camera·Quick Start Guide

3 Setting the Network Camera over the

LAN

Note:

You shall acknowledge that the use of the product with Internet

access might be under network security risks. For avoidance of any

network attacks and information leakage, please strengthen your

own protection. If the product does not work properly, please

contact with your dealer or the nearest service center.

Wiring 3.1

Please connect to the camera to the network according to the

following figures

半球

Network Cable

Network Camera

Computer

Connecting Directly Figure 3-1

网络交换机

半球

Network Cable

Network Camera Computer

Connecting via a Switch or a Router Figure 3-2

Questions and Answers:

Need help?

Do you have a question about the HIKVISION DS-2CD6986F and is the answer not in the manual?

HIKVISION DS-2CD6986F Specifications

General

Type	IP security camera
Certification	CE
Placement supported	-
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Sensor type	CMOS
Optical sensor size	1/1.8 \
Pan range	0 - 360 °
Tilt angle range	45 - 90 °
Camera shutter speed	1/25 ~ 1/100000 s
Minimum illumination	0.002 lx
Fixed focal length	5 mm
Lens mount interface	CS mount
Total megapixels	7.3 MP
Maximum resolution	4096 x 1800 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, M-JPEG
Supported graphics resolutions	1920 x 1200 (WUXGA), 3840 x 2400
Audio input channels	1 channels
Password protection type	User
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3at
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, QoS, IPv6, Bonjour
Interface	RJ-45/RS-485
Ethernet LAN (RJ-45) ports	1
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
IK code	IK10
Form factor	Dome
Product color	White
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	22 W
