HIKVISION DS-2CE12D0T-PIRXF User Manual

1 Introduction
1.1 Product Features
The main features are as follows:
 High performance CMOS sensor
 OSD menu with configurable parameters
 Smart IR
 PIR detection
 Built-in siren
 4 in 1 video output
1.2 Overview
1.2.1 Overview of Type I Camera
Lens
PIR
Siren
Main Body
Bracket
Power Cord
Video Cable
Switch Button
Figure 1-1 Overview of Type I Camera
Note:
Press and hold the switch button for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS.
1.2.2 Overview of Type II Camera
Enclosure
PIR
Lens
Main Body
Switch Button
Video Cable
Power Cord
Mounting
Base
Figure 1-2 Overview of Type II Camera
Note:
Press and hold the switch button for 5 seconds to
switch the video output. Four kinds of video outputs
are available: TVI, AHD, CVI, and CVBS.

HIKVISION DS-2CE12D0T-PIRXF Specifications

General

Brand	HIKVISION
Model	DS-2CE12D0T-PIRXF
Category	Security Camera
Language	English
