UM DS-2CE1xU8T-ITx 042618NA 4
1.1.8 Mark Description
Table 0-1 Mark Description
2 Introduction
2.1 Product Features
The camera is applicable for both indoor and outdoor
conditions. Application scenarios include roads,
warehouses, underground parking lots, bars, etc..
The main features are as follows:
• 8 MP high performance CMOS sensor
• IR cut filter with auto switch
• OSD menu with configurable parameters
• Auto white balance
• internal synchronization
• SMART IR mode
• 3-axis adjustment
2.2 Overview
This manual applies to two types of bullet cameras.
The overviews of each type are shown in the figures
below.
2.2.1 Overview of Type I Camera
Figure 1 Overview of Type I Camera
2.1.1
Overview of Type II Camera
Figure 2 Overview of Type II Camera
3 Installation
Before you start:
• Make sure that the device in the package is in good
condition and all the assembly parts are included.
• Make sure that all the related equipment is
powered off during the installation.
