User Manual of Network Speed Dome
© Hikvision
1
Chapter 1 Overview
1.1 System Requirement
System requirement of web browser accessing is as follows:
Operating System: Microsoft Windows XP SP1 and above version/Vista/Win7/Server 2003/Server
2008 32bits
CPU: Intel Pentium IV 3.0 GHz or higher
RAM: 1G or higher
Display: 1024 × 768 resolution or higher
Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.02 and above version,
Mozilla Firefox 5 and above version and Google Chrome 18 and above versions.
1.2 Functions
The functions vary depending on different camera models.
PTZ Limits
The camera can be programmed to move within the PTZ limits (left/right, up/down).
Scan Modes
The camera provides 5 scan modes: auto scan, tilt scan, frame scan, random scan and panorama
scan.
Presets
A preset is a predefined image position. When the preset is called, the camera will automatically
move to the defined position. The presets can be added, modified, deleted and called.
Label Display
The on-screen label of the preset title, azimuth/elevation, zoom, time and camera name can be
displayed on the monitor. The displays of time and camera name can be programmed.
Auto Flips
In manual tracking mode, when a target object goes directly beneath the camera, the video will
automatically flips 180 degrees in horizontal direction to maintain continuity of tracking. This
function can also be realized by auto mirror image depending on different camera models.
Privacy Mask
This function allows you to block or mask certain area of a scene, for preventing the personal
privacy from recording or live viewing. A masked area will move with pan and tilt functions and
automatically adjust in size as the lens zooms telephoto and wide.
3D Positioning
In the client software, use the left key of mouse to click on the desired position in the video
image and drag a rectangle area in the lower right direction, then the camera system will move
the position to the center and allow the rectangle area to zoom in. Use the left key of mouse to

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-2DE5425IW-AE and is the answer not in the manual?

HIKVISION DS-2DE5425IW-AE Specifications

General IconGeneral
TypeIP security camera
Languages supportBUL, CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, THA, TUR
Number of languages32
Placement supportedOutdoor
Connectivity technologyWired
Infrared (IR) cut-off filterYes
Total megapixels4 MP
Gain control typeAuto/Manual
Maximum resolution2560 x 1440 pixels
Video compression formatsH.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology3D noise reduction
Supported graphics resolutions352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2560 x 1440
Number of cameras1
Sensor typeCMOS
Optical sensor size1/2.8 \
FocusMotorized/Manual
Digital zoom16 x
Optical zoom25 x
Focal length range- mm
Maximum aperture number3.5
Minimum aperture number1.6
Closest focusing distance0.01 m
Pan range0 - 360 °
White balanceATW, Auto, Fluorescent, Indoor, Manual, Outdoor, Sodium lamp
Pan preset speed120 °/sec
Tilt angle range-15 - 90 °
Camera shutter speed1/1 - 1/30000 s
Minimum illumination0 lx
LED typeIR
Night vision distance150 m
Voice codecsG.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM
Audio input channels1 channels
Behavior analysisIntrusion detection, Line crossing detection, Object removal detection, Unattended baggage detection
Built-in HDDNo
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size256 GB
Number of users32 user(s)
Networking standardsIEEE 802.1x
Ethernet interface typeFast Ethernet
Supported network protocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Operating temperature (T-T)-30 - 65 °C
Operating relative humidity (H-H)0 - 90 %
Power source typeDC
Power consumption (max)30 W
Form factorDome
Mounting typeCeiling/wall
Product colorWhite
International Protection (IP) codeIP66
Weight and Dimensions IconWeight and Dimensions
Height345 mm
Weight3300 g
Diameter208 mm
