Detection Target: You can select human, vehicle, or all (human &vehicle) as the detection
target from the dropdown list. If Human is selected, only human beings will be identified
as detection objects and as well as Vehicle.
Notes:
• For network cameras, regions can be set simultaneously before clicking Save button.
For speed domes, you need to set 1 region and save it. Then continue to set and save
the next region.
• For speed domes, you can set regions in scenes respectively. Then configure park
settings. Speed dome parks among regions. Refer to Park among Regions.
7. Click tab to enter the arming schedule setting interface. The time
schedule configuration is the same as the settings of the arming schedule for motion
detection. Refer to Section 5.2.1 Configuring Motion Detection.
8. Click tab to select the linkage method taken for intrusion detection, Notify
Surveillance Center, Send Email, Upload to FTP/Memory Card/NAS, Trigger Alarm Output and
Trigger Recording are selectable. Refer to Section 5.2.1 Configuring Motion Detection.
9. Click to save the settings.
5.3.4 Configuring Line Crossing Detection
The virtual plane detection can be adopted for the intrusion detection. Once the virtual plane is
detected being traversed according to the configured direction, a set of alarm action is triggered.
Steps:
1. Enter the Line Crossing Detection interface:
Configuration >Event > Smart Event > Line Crossing Detection
2. Check the Enable checkbox to enable the line crossing detection function.
3. Select the Line in dropdown list to configure.
4. The event triggered and park action related PTZ movement will be locked for 180 seconds
after you enter the line crossing detection interface. Optionally, you can click the
button to manually activate the movement, or lock the movement
when the button turns to by clicking it.
