capture settings interface to edit the segment capture parameters. (optional)
Figure 5-4 Segment Snapshot Settings
6. Click to enter the advanced setting interface. You can select the stream type of
the capture.
7. Click to enter the Capture Parameters Interface.
8. Check the Enable Timing Snapshot checkbox to enable continuous snapshot, and configure
the schedule of timing snapshot. Check the Enable Event-triggered Snapshot checkbox to
enable event-triggered snapshot.
9. Select the format, resolution, quality of the snapshot.
10. Set the time interval between two snapshots.
11. Click to save the settings.
Uploading to FTP
Make sure that the FTP server is online.
You can follow below configuration instructions to upload the snapshots to FTP.
 Upload continuous snapshots to FTP
Steps:
1) Configure the FTP settings and check Upload Picture checkbox in FTP Settings interface.
Refer to Section 6.1.2 Configuring FTP Settings for more details to configure FTP parameters.
2) Check the Enable Timing Snapshot checkbox.
3) Click Edit to set the snapshot schedule. Refer to Section 5.2.1 Configuring Motion
Detection.
 Upload event-triggered snapshots to FTP
Steps:
1) Configure the FTP settings and check Upload Picture checkbox in FTP Settings interface.
Refer to Section 6.1.2 Configuring FTP Settings for more details to configure FTP parameters.
2) Check Upload to FTP checkbox in Motion Detection Settings or Alarm Input interface. Refer
to Section 5.2.1 Configuring Motion Detection.
3) Check the Enable Event-triggered Snapshot checkbox.

HIKVISION DS-2DE5425IW-AE Specifications

General

Type	IP security camera
Languages support	BUL, CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, THA, TUR
Number of languages	32
Placement supported	Outdoor
Connectivity technology	Wired
Infrared (IR) cut-off filter	Yes
Total megapixels	4 MP
Gain control type	Auto/Manual
Maximum resolution	2560 x 1440 pixels
Video compression formats	H.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology	3D noise reduction
Supported graphics resolutions	352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2560 x 1440
Number of cameras	1
Sensor type	CMOS
Optical sensor size	1/2.8 \
Focus	Motorized/Manual
Digital zoom	16 x
Optical zoom	25 x
Focal length range	- mm
Maximum aperture number	3.5
Minimum aperture number	1.6
Closest focusing distance	0.01 m
Pan range	0 - 360 °
White balance	ATW, Auto, Fluorescent, Indoor, Manual, Outdoor, Sodium lamp
Pan preset speed	120 °/sec
Tilt angle range	-15 - 90 °
Camera shutter speed	1/1 - 1/30000 s
Minimum illumination	0 lx
LED type	IR
Night vision distance	150 m
Voice codecs	G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM
Audio input channels	1 channels
Behavior analysis	Intrusion detection, Line crossing detection, Object removal detection, Unattended baggage detection
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB
Number of users	32 user(s)
Networking standards	IEEE 802.1x
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Operating temperature (T-T)	-30 - 65 °C
Operating relative humidity (H-H)	0 - 90 %
Power source type	DC
Power consumption (max)	30 W
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
International Protection (IP) code	IP66

Weight and Dimensions

Height	345 mm
Weight	3300 g
Diameter	208 mm
