User Manual of Network Speed Dome
© Hikvision
10
rendition function of the camera to adjust the color temperature according to the
environment automatically.
Patrol
A patrol is a memorized series of pre-defined preset function. The scanning speed
between two presets and the dwell time at the preset are programmable.
Pattern
A pattern is a memorized series of pan, tilt, zoom, and preset functions. By default
the focus and iris are in auto status during the pattern is being memorized.
Power Off Memory
The dome supports the power off memory capability with the predefined resume
time. It allows the dome to resume its previous position after power is restored.
Time Task
A time task is a preconfigured action that can be performed automatically at a
specific date and time. The programmable actions include: auto scan, random scan,
patrol 1-8 ,pattern 1-4, preset 1-8,frame scan, panorama scan, tilt scan, day, night,
reboot, PT adjust, Aux Output, etc.
Park Action
This feature allows the dome to start a predefined action automatically after a period
of inactivity.
User Management
The dome allows you to edit users with different levels of permission, in the admin
login status. Multiple users are allowed to access and control the same network
speed dome via network simultaneously.
3D Digital Noise Reduction
Comparing with the general 2D digital noise reduction, the 3D digital noise reduction
function processes the noise between two frames besides processing the noise in
one frame. The noise will be much less and the video will be clearer.
Dual-VCA
Combine the detected VCA information into the video stream, which can be used for
the second-time analysis on the back-end device.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-2DF5286-AEL and is the answer not in the manual?

HIKVISION DS-2DF5286-AEL Specifications

General IconGeneral
TypeIP security camera
PTZ controlYes
Placement supportedOutdoor
Connectivity technologyWired
Form factorDome
Mounting typeWall
Product colorWhite
International Protection (IP) codeIP66
Total megapixels2 MP
Maximum resolution1920 x 1080 pixels
Supported video modes1080p, 720p
Video formats supportedH.264, MPEG4
Supported graphics resolutions1280 x 960, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Pan range0 - 360 °
Pan speed300 °/sec
White balanceATW, Auto, Indoor, Lamp, Manual, Outdoor
Tilt angle range-5 - 90 °
Camera shutter speed1 - 1/10000 s
Minimum illumination0.03 lx
Field of view (FOV) angle58.9 °
Sensor typeCMOS
Optical sensor size1/2.8 \
Digital zoom16 x
Optical zoom30 x
Focal length range- mm
Password protection typeUser
Built-in HDD-
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size32 GB
LED typeIR
Wi-FiNo
Cabling technology10/100Base-T(X)
Supported network protocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE
Ethernet LAN (RJ-45) ports1
Signal-to-Noise Ratio (SNR)52 dB
AC input voltage24 V
Power source typePoE
Power consumption (max)65 W
Operating temperature (T-T)-40 - 65 °C
Operating relative humidity (H-H)0 - 90 %
Weight and Dimensions IconWeight and Dimensions
Height305 mm
Weight5000 g
Diameter220 mm
