6.6.14 Unattended Baggage Detection
Purpose:
Unattended baggage detection function detects the objects left over in the
pre-defined region such as the baggage, purse, dangerous materials, etc., and a
series of actions can be taken when the alarm is triggered.
Steps:
1. Enter the Unattended Baggage Detection settings interface:
Configuration> Advanced Configuration> Smart Event> Unattended Baggage
Detection
2. Check the checkbox of Enable Unattended Baggage Detection to enable the
function.
Figure 6-62 Configuring Unattended Baggage Detection
3. Select the region from the drop-down list for detection settings.
4. Click the button to start the region drawing.
5. Click on the live video to specify the four vertexes of the detection region, and
right click to complete drawing.
6. Set the time threshold and detection sensitivity for unattended baggage
detection.
Threshold: Range [1-100]s, the threshold for the time of the objects left over in
the region. If you set the value as 10, alarm is triggered after the object is left
and stay in the region for 10s.
Sensitivity: Range [1-100]. The value of the sensitivity defines the similarity
degree of the background image. Usually, when the sensitivity is high, a very
small object left in the region can trigger the alarm.
7. Repeat the above steps to configure other regions. Up to 4 regions can be set.
