6.6.2 Configuring Video Loss Alarm
Steps:
1. Enter the Video Loss Setting interface:
Configuration > Advanced Configuration> Basic Event > Video Loss
Figure 6-50 Video Loss
2. Check the Enable Video Loss Detection checkbox to enable the video loss
detection.
3. Click to edit the arming schedule for video loss detection. The arming
schedule configuration is the same as the setting of the arming schedule for
motion detection. Refer to Step 2 in Section 6.6.1 Configuring Motion Detection.
4. Check the checkbox to select the linkage method taken for the video loss alarm,
notify surveillance center, send email and trigger alarm output are selectable.
Please Step 3 in Section 6.6.1 Configuring Motion Detection.
5. Click to save the settings.
6.6.3 Configuring Video Tampering Alarm
Purpose:
