User Manual of IR Network Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
Figure 4-8 Adding Presets
4. Configure the preset number, patrol duration and patrol speed.
It is the duration staying on one patrol point. The speed
dome moves to another patrol point after the patrol
time.
It is the speed of moving from one preset to another.
5. Click to save a preset into the patrol.
6. Repeat the steps from 3 to 5 to add more presets.
7. Click to save all the patrol settings.
Calling a Patrol:
In the PTZ control panel, select a defined patrol from and click
to call the patrol as shown in Figure 4-9.
