User Manual of IR Network Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
30
Figure 4-11 Remaining Memory
5. Click to save all the pattern settings.
 Buttons on the Patterns interface:
Buttons
Description
Start to record a pattern.
Stop recording a pattern.
Call the current pattern.
Stop the current pattern.
Delete the current pattern.
Notes:
 These 4 patterns can be operated separately and with no priority level.
 When configuring and calling the pattern, proportional pan is valid; the limit
stops and auto flip will be invalid; and the 3D positioning operation is not
supported.
4.6 Configuring Live View Parameters
 Main stream/Sub-stream/Third stream:
You can select , or as the stream type of
live viewing. The main stream is with a relatively high resolution and needs much
bandwidth. The sub-stream is with a low resolution and needs less bandwidth. The
resolution of third stream is between that of main stream and sub stream. The
default setting of stream type is .
Note: Please refer to Section 6.4.1 Configuring Video Settings for more detailed
parameter settings of the main stream, sub-stream and third stream respectively.
 Image Size:
You can scale up/down the live view image by clicking . the
