You may need to use the OSD (On Screen Display) menu when controlling the speed dome
remotely. To display the OSD menu on the live view screen, you can call the preset number
95.
4.4.6 Setting / Calling a Patrol
Purpose:
A patrol is a memorized series of preset function. It can be configured and called on the patrol
settings interface. There are up to 8 patrols for customizing. A patrol can be configured with 32
presets.
Before you start:
Please make sure that the presets you want to add into a patrol have been defined.
Setting a Patrol:
Steps:
1. In the PTZ control panel, click to enter the patrol settings interface.
2. Select a patrol number from the list and click .
3. Click to enter the adding interface of preset, as shown in Figure 4-9.
Figure 4-9 Adding Presets
4. Configure the preset number, patrol time and patrol speed.
It is the duration staying on one patrol point. The speed dome
moves to another patrol point after the patrol time.
