Network Mini Dome Camera·Quick Start Guide
5. Adjust the surveillance angle.
Plastic Ring
Pan: -30° to 30°
Tilt: 0° to 80°
Rotate: 0° to 360°
3-Axis Adjustment
1). View the image via the web browser.
2). Slightly loosen the screw beside the RESET button to adjust
the surveillance angle.
3). Stick the supplied plastic ring in the camera. Hole and move
the ring to adjust the panning, tilting, and rotating position
to get the desired angle.
4). Remove the plastic ring and tighten the hex screw to finish
adjustment.
6. Install the dome cover back to the camera.
