HIKVISION DS-2XM6222FWD-I User Manual

Network Mobile Camera·Quick Start Guide
14
14
Screw
Spring Washer
Flat Washer
Nut
Secure the Bracket Base Figure 2-3
5. Loosely screw the camera back to the bracket base.
6. Adjust the tilting position.
-
+
+
-
Tilt:
+20° to -15°
Pan:
+20° to -20°
Adjust Surveillance Angle Figure 2-4
7. Tighten the screws to finish installation.

HIKVISION DS-2XM6222FWD-I Specifications

General

Brand	HIKVISION
Model	DS-2XM6222FWD-I
Category	Security Camera
Language	English
