HIKVISION DS-3E0105P-E User Manual

Safety Instruction
These instructions are intended to ensure that user can user the product correctly to avoid danger
or property loss.
The precaution measure is divided into “Warning” and “Caution”.
Warning: Serious injury or death may occur if any of the warning is neglected.
Caution: Injury or equipment damage may occur if any of the caution is neglected.
Warning Follow these safeguards
to prevent serious injury or death.
Caution Follow these precautions
to prevent potential injury or
material damage.
Warning
 Proper configuration of all passwords and other security settings is the responsibility of the
installer and/or end-user.
 In the use of the product, you must be in strict compliance with the electrical safety
regulations of the nation and region. Refer to technical specifications for detailed
information.
 Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited
Power Source with 100-240 V AC or 12 V DC according to the IEC60950-1 standard. Refer
to technical specifications for detailed information.
 Do not connect several devices to one power adapter as adapter overload may cause
over-heating or a fire hazard.
 Make sure that the plug is firmly connected to the power socket.
If smoke, odor or noise rise from the device, turn off the power at once and unplug the power
cable, and then contact the service center.

HIKVISION DS-3E0105P-E Specifications

General

Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	5
Maximum data transfer rate	100 Mbit/s
Input voltage	51 V
Output current	1.25 A
Power supply included	Yes
Power consumption (max)	63 W
Surge protection voltage	4 kV
Power consumption (typical)	632 W
Number of power supply units	1
10G support	No
Switch type	Unmanaged
Stackable	-
Product color	Blue
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Total Power over Ethernet (PoE) budget	58 W
Power over Ethernet (PoE) ports quantity	4
Power over Ethernet (PoE) power per port	15.4 W
MAC address table	1000 entries
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	93.3 mm
Width	132 mm
Height	27.6 mm
Weight	299 g
