HIKVISION DS-3E0105P-E User Manual

Unmanaged PoE Switch/User Manual
2
LED Indicators
Specific description of the LED indicators is shown as follows:
LED
State
Description
Power
Solid on
The switch is connected to a power supply
properly.
Off
The switch is connected to a power supply
improperly or not connected to a power
supply.
PoE
(on the upper right
corner of ports 1-4)
Solid on
The port is supplying power to the device
connected to it properly.
Off
The port is not supplying power or not
connected to a powered device.
Link/Act
(on the upper left corner
of ports 1-5)
Solid on
The port is connected properly.
Blinking
Data is being transmitted over the port.
Off
The port is connected improperly or not
connected to a device.
Link/Act LED
Power LED
PoE port
Uplink port
PoE LED
Link/Act LED

HIKVISION DS-3E0105P-E Specifications

General

Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN (RJ-45) ports	5
Maximum data transfer rate	100 Mbit/s
Input voltage	51 V
Output current	1.25 A
Power supply included	Yes
Power consumption (max)	63 W
Surge protection voltage	4 kV
Power consumption (typical)	632 W
Number of power supply units	1
10G support	No
Switch type	Unmanaged
Stackable	-
Product color	Blue
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Total Power over Ethernet (PoE) budget	58 W
Power over Ethernet (PoE) ports quantity	4
Power over Ethernet (PoE) power per port	15.4 W
MAC address table	1000 entries
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	93.3 mm
Width	132 mm
Height	27.6 mm
Weight	299 g
