Table 11 Specifications for DS-7224/7232HVI-SH
Model
DS-7224HVI-SH DS-7232HVI-SH
Video/Audio
input
Video compression H.264
Video input 24-ch 32-ch
Video input interface BNC (1.0 Vp-p, 75 Ω), PAL /NTSC self-adaptive
Audio compression G.711u
Audio input 4-ch, RCA (2.0 Vp-p, 1 kΩ)
Two-way audio input 1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Video/Audio
output
HDMI/VGA output
1-ch, resolution:
1080P: 1920×1080P/60Hz, SXGA: 1280×1024/60 Hz,
720P: 1280×720/60 Hz, XGA: 1024×768/60 Hz
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
Encoding resolution WD1/ 4CIF / 2CIF / CIF / QCIF
Frame rate
WD1 / 4CIF @ 15 fps or
2CIF / CIF / QCIF @ 25 fps (P) / 30 fps (N)
Video bit rate 32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps)
Audio output 1-ch, RCA (Linear, 1 kΩ)
Audio bit rate 64 Kbps
Dual-stream
Support;
Sub-stream: CIF / QCIF
Stream type Video, Video & Audio
Synchronous
playback
16-ch
Hard disk
SATA 2 SATA interface
Capacity Up to 4TB capacity
External
interface
Network interface 1, RJ45 10M /100M /1000M Ethernet interface
Serial interface 1 RS-485 interface, half-duplex
USB interface 2, USB 2.0
Alarm in 4
Alarm out 1
General
Power supply 12 VDC
Consumption
(without hard disk or
DVD-R/W)
≤ 25 W
Working temperature -10 ºC ~+55 ºC
Working humidity 10% ~ 90%
Chassis 19-inch rack-mounted 1U chassis
Dimensions
(W × D × H)
445 × 290 × 45 mm
Weight (without hard
disk or DVD-R/W)
≤ 4 kg
