HIKVISION DS-7204HGHI-F1

Digital Video Recorder User Manual
277
18.1.7 DS-7100HQHI-F1/N
Model
DS-7104HQHI-F1
/N
DS-7108HQHI-F1
/N
DS-7116HQHI-F1/
N
Video/Audio
input
Video
compression
H.264+/H.264
Analog video
input
4-ch
8-ch
16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI input
3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60
Note: The 3 MP signal input is only available for the first channel
of DS-7104HQHI-F1/N, the first 2 channels of
DS-7108HQHI-F1/N, and the first 4 channels of
DS-7116HQHI-F1/N.
AHD input
1080p25, 1080p30, 720p25, 720p30
HDCVI input
1080p25, 1080p30, 720p25, 720p30
CVBS input
Support
Audio
compression
G.711u
Audio input/
Two-way
audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ)、
Video/Audio
output
HDMI/VGA
output
1-ch, 1920 × 1080/60Hz,1280 ×
1024/60Hz, 1280 × 720/60Hz, 1024 ×
768/60Hz
HDMI: 1-ch, 4K
(3840 × 2160)/30Hz,
2K (2560 ×
1440)/60Hz, 1920 ×
1080/60Hz, 1280 ×
1024/60Hz, 1280 ×
720/60Hz, 1024 ×
768/60Hz
VGA: 1-ch, 2K (2560
× 1440)/60Hz, 1920
× 1080/60Hz, 1280 ×
1024/60Hz, 1280 ×
720/60Hz, 1024 ×
768/60Hz
Encoding
When 1080p Lite mode not enabled:
