HIKVISION DS-7204HGHI-F1 User Manual

Digital Video Recorder User Manual
143
6.2.2 Digital Zoom
Step 1 Click the button on the playback control bar to enter Digital Zoom interface.
Step 2 Use the mouse to draw a red rectangle and the image within it will be enlarged up to 16
times.
Figure 6-24 Draw Area for Digital Zoom
Step 3 Right-click the image to exit the digital zoom interface.
6.2.3 Reverse Playback of Multi-Channel
Purpose
You can play back record files of multi-channel reversely. Up to 16-ch simultaneous reverse
playback is supported.
Step 1 Enter Playback interface.
Menu>Playback
Step 2 Check more than one checkboxes to select multiple channels and click to select a date on
the calendar.

HIKVISION DS-7204HGHI-F1 Specifications

General

Voltage	12 V
Product color	Black
Rack capacity	1U
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Video input channels	4 channels
USB 2.0 ports quantity	2
Power consumption (typical)	8 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	1000 g
Dimensions (WxDxH)	260 x 222 x 45 mm
