DS-7200-ST Series DVR Quick Operation Guide
31
DS-7200HFI-ST/RW:
Model
DS-7204HFI-ST/RW
DS-7208HFI-ST/RW
DS-7216HFI-ST/RW
Video/Audio
input
Video compression H.264
Analog video input
4-ch
8-ch
16-ch
Video input
interface
BNC connector (1.0 Vp-p, 75 Ω); PAL / NTSC adaptive
Audio compression
G.71 1
Audio input 4-ch, RCA connector (2.0 Vp-p, 1 kΩ)
Voice talk input 1-ch, RCA (2.0 Vp-p, 1 kΩ)
VGA output 1-ch, resolution: 1280 × 1024 / 60 Hz, 1024 × 768 / 60 Hz
CVBS output
2-ch, BNC connector (1.0 Vp-p, 75 Ω); Resolution: PAL: 704 × 576,
NTSC: 704 × 480
Audio output
1-ch, RCA connector (Linear, 1 kΩ)
Video/Audio
output
Recording
resolution
4CIF / 2CIF / CIF
Frame rate
Main stream:
4CIF / 2CIF / CIF@25 fps (P) / 30 fps (N)
Sub stream:
CIF@6 fps, QCIF@25 fps (P) / 30 fps (N)
Video bit rate 32 kbps ~ 2048 kbps, or user-defined (Max. 3072 kbps)
Stream type
Video/ Video & Audio
Audio bit rate 64 kbps
Dual stream
Support
Synchronous
playback
4-ch 8-ch 16-ch
Hard disk
Type
2 SATA interfaces
Capacity Up to 2TB capacity for each interface
External
interface
Network interface
1, RJ45 10 M / 100 M adaptive Ethernet interface
Serial interface 1 RS-485 full-duplex interface, 1 RS-232 interface
USB interface
2, USB 2.0
Alarm in 4 8 16
Alarm out
1
4
4
Others
Power supply 12 VDC
Consumption
≤10 W (without hard
disk or DVD-R/W)
≤15 W (without hard
disk or DVD-R/W)
≤20 W (without hard
disk or DVD-R/W)
Working
temperature
-10 ºC ~ +55 ºC
Working humidity
10% ~ 90%
Chassis
19-inch rack-mounted 1.5U chassis
Dimensions
(W× D× H)
440 × 390 × 70 mm
Weight ≤ 8 kg (without hard disk or DVD-R/W)
